Glow Discharge Optical Emission Spectroscopy

A Practical Guide

By Thomas Nelis, Richard Payling

The Royal Society of Chemistry

Copyright © 2003 The Royal Society of Chemistry
All rights reserved.
ISBN: 978-0-85404-521-1

Contents

Chapter 1 Preparation and Maintenance of Instrument, 1,
Chapter 2 Samples: Selection and Preparation, 11,
Chapter 3 Optimisation of Source and Analytical Parameters, 21,
Chapter 4 Calibration, 45,
Chapter 5 Calibration for Bulk Analysis, 76,
Chapter 6 Calibration for Compositional Depth Profiling, 82,
Chapter 7 Drift Correction, 103,
Chapter 8 Bulk Analysis, 110,
Chapter 9 Qualitative Depth Profiling, 123,
Chapter 10 Compositional Depth Profiling, 136,
Chapter 11 Theory, 147,
Chapter 12 Line Selection, 178,
Chapter 13 Troubleshooting, 187,
Further Reading, 193,
Appendix, 194,
Index, 209,

CHAPTER 1

Preparation and Maintenance of Instrument

There are several different designs of GDOES instruments available on the market and they range in size from small bench-top units to large laboratory systems, depending mainly on the focal length of the spectrometer. The largest GDOES instrument ever built, one of the first but no longer made, had a focal length of 2.5 m. Today, spectrometers vary between 150 mm and 1 m in focal length. Despite these variations in size, they all have many features in common (shown in block form in Figure 1.1):

• glow discharge source

• optical spectrometer(s)

• vacuum pump(s)

• electronics

• computer and printer

• services: electricity, ultra-high purity argon

Some have additional services: water cooling, high purity nitrogen (for spectrometer), compressed air (for pneumatic valves) and a computer network/Internet connection.

Before beginning work on an instrument, the first thing to do is to check that each of these components is up and running. Walk around the instrument. Check that the area is tidy and the cables are connected. Check the services are working: electricity, gas(es) and cooling water. If necessary, check that the vacuum pump(s) is working. Check that the GD source is clean and ready and the computer is on. Run a common bulk sample for several minutes to ‘condition’ the source, i.e. warm and clean the source through normal operation. If necessary, check the alignment of the spectrometer(s). The instrument should now be ready.

Glow discharge spectrometers, like most analytical instruments, need regular maintenance and preparation for measurements. So, besides this initial inspection, consider regular maintenance checks. The purpose of maintenance is at least two-fold:

• to avoid serious trouble with the instrument and

• to avoid bad/wrong measurements

Checking the instrument before starting the analysis not only avoids trouble during the measurement, but also helps the operator to concentrate on the task of getting excellent results, as it liberates the mind from constant worries such as:

• Is my computer system stable?

• Is there enough argon?

• Do we have a leak in the source?

It is beyond the scope of this book to give detailed instructions for the maintenance of all instruments currently available on the market. For details on routine maintenance specific to your instrument, refer to the user’s manual supplied with your instrument. In the following, we will provide general advice on maintenance procedures that will help save time in the long run and improve the overall quality of the analyses.

1 Before Starting Measurements

We will now consider preparation in more detail. Before starting to operate your instrument, make sure the computer and the software are in stable condition. This implies:

• if necessary, restart the system

• check the available space on the hard disk regularly

• archive the data you definitely do not want to lose

Checking the different supplies, such as gas, water and electricity, before starting analysis should become a habit. The argon supply pressure must be in the range specified by the instrument manufacturer. A different argon supply pressure may seriously affect the performance of the argon pressure regulation in the discharge chamber. When using gas bottles, be aware that the last 10% of the bottle may no longer meet the quality required. When replacing argon bottles, avoid getting air into the argon gas line.

Make sure the cooling system(s) is operating properly:

• check the water supply for open (non-return) systems or

• check the level of the cooling liquid for closed (recirculating) systems

• check for particles in the closed cooling liquid; if necessary replace the liquid

Make sure no power failure has occurred since you last operated the instrument, as this may seriously affect the condition of the instrument. For example, a long time without power may have affected the thermal regulation of the spectrometer, so the instrument may need time to stabilise. A common guide for larger, heated spectrometers is 1 hour stabilising time, up to a maximum of 8 hours, for each hour without electrical power.

When the instrument has not been used for some time, it is generally recommended to run a few dummy samples, before optimal stability can be achieved. This effect may be more or less important, depending on the design of the instrument.

2 Routine Checks

Perform regular routine analyses on samples of known chemical composition. If your instrument is used for depth profiling, these samples should include homogeneous reference materials as well as coated materials (see, e.g. Figure 1.2).

The purpose of these tests is to assess, verify and finally establish in written or recorded form the current performance of the instrument. They also help to detect possible malfunctions of the instrument, prior to analysis. Another result of routine checks on samples of known composition is the possibility of measuring the long-term precision and accuracy of the instrument for a given application, and the frequency required for drift corrections.

For bulk analysis, we suggest you analyse two different homogeneous samples, one a low-alloyed material and the other a high-alloyed material. The chosen materials should have a large number of specified elements. In particular, the elements contained in air, namely N, O, C and H, should be checked to make sure no air leak has occurred, as only a small amount of air in the discharge chamber can drastically change the nature of the glow discharge plasma, for all elements.

Analysing a coated sample allows you to monitor the sputtering rate and depth resolution. The sample used for routine checks should therefore be homogeneous in coating thickness and should have clearly defined interfaces between the different layers.

3 Monitoring Key Parameters Over Time

To monitor the performance of the instrument and to detect malfunctions before they become significant in the analytical results, the following key parameters should be monitored over time:

• intensities

• source impedance

An example is shown in Figure 1.3. These charts allow quick troubleshooting and can be used to plan preventative maintenance, thereby reducing unscheduled downtime.

Monitoring the intensities of the elements, N, O, C and H, overtime, if they increase significantly or suddenly, can help detect air leaks in the argon supply system. All the wavelengths shown in this book are in nanometre (nm).

Monitoring the impedance of the GD source for a given sample canbe used to record the reproducibility of the plasma, i.e. of the sputtering and excitation processes. In particular, it can be used to monitor the pressure regulation and any changes in the anode-to-sample gap over time, with the eventual need to replace the anode if the gap becomes too large. Changes in source impedance can be monitored, in RF operation, at fixed applied power and pressure by recording changes in the DC bias voltage or applied voltage over time. In DC operation, the voltage can be recorded at fixed current and pressure.

4 Anode-to-Sample Gap

The anode-to-sample gap is one parameter that has generally been neglected in most work on glow discharge spectroscopy. Though it is not so difficult to measure, no manufacturer currently provides a routine way of doing it. Despite this negligence, the anode-to-sample gap is a crucial parameter for reproducible GDOES data. Increasing the anode-to-sample gap increases the source impedance. This change in source impedance then affects the relationship between current and voltage in the plasma. The effect is shown in Figure 1.4 for a large change in anode gap from 0.12 mm to 0.30 mm. Such a change, if undetected, would have dramatic effects on the validity of calibration curves and the accuracy of analysis.

An anode-to-sample gap between 0.08 mm and 0.2 mm is generally recommended. Small gaps are usually beneficial for improving depth resolution; larger gaps allow running the discharge for longer times without creating a short circuit between the anode and the sample. Whatever gap is chosen by the manufacturer or the operator, it should be kept constant for a given type of analysis. Variations in gap size will lead to variations in glow discharge conditions and thereby alter the analytical results.

The anode-to-sample gap can be measured with a specially adapted micrometer screw gauge (see Figure 1.5). Ideally, it should be capable of measuring the gap to within [+ or -]10 µm. If no such device is available, one way of suspecting that the gap is getting too large is that it becomes more difficult to get flat craters, especially with typical source conditions.

5 Centring the Spectrometer

GDOES instruments containing a polychromator(s) built on the Paschen-Runge design, with a movable entrance (primary) slit, fixed exit slits and photomultiplier tubes as detectors, need occasional centring of the primary slit. This generally means the entrance slit of the spectrometer is moved to give maximum intensity on one specific line. The result is that all other lines on the polychromator will also be centred simultaneously. How well this works depends on how well the secondary slits were aligned during manufacture of the spectrometer. An example is shown in Figure 1.6.

Depending on the design of the spectrometer, this operation needs to be performed every day, occasionally or only once the polychromator has been opened. It is a good practice to use the same conditions (method) and the same sample and to note the changes in peak position and intensity. This will indicate if there is a problem in the spectrometer, such as change in temperature, or if the window needs cleaning.

Scanning monochromators in the Czerny-Turner design also require occasional alignment, because of the movement of the grating, typically using the zero-order reflection from the grating and argon reference lines. A useful argon reference line is at 415.859 nm.

Spectrometers using CCD detectors to cover wide ranges of the spectrum generally do not need this operation, as it can be integrated directly in the mathematical algorithms used for line identification. Nevertheless, the assignment between pixel number and wavelength should be checked from time to time and, if there are systematic errors, a new function should be applied.

6 Window Cleanliness

Monitoring intensities over time for selected elemental lines covering a wide range of wavelengths allows checking the performance of the optical spectrometer. A continuous decrease of all intensities, being most severe at short wavelengths, would indicate increasing pollution of the optics, particularly the window between the glow discharge and the optical spectrometer. An example is shown in Figure 1.7. In this example, the intensities of the many lines on a polychromator were measured for two samples, Zn-Al alloy Canmet ZN3 and Steel NBS 1262, soon after cleaning the window and then 3 weeks later, after analysing a large number of other samples, including many paint coatings. The intensities after 3 weeks were then divided by the intensities with the clean window. After seeing these results it was decided, for this particular instrument, to clean the window every week. For other instruments analysing other materials, it is common to clean the window only once a month, or even less frequently. This decision will vary from laboratory to laboratory and is best decided from experience and from data over time.

Contamination of the window can occur from sputtered material. Grimm-type sources are designed to have a counter-flow of argon that travels across the window and is then directed towards the sample to minimise deposition on the window. Sometimes pollution comes from the oil pumps used in the source, and sometimes from the evaporation of low-temperature samples, e.g. tin or lead. Oil will tend to accumulate in places with the lowest temperature. Clearly, the source should not be at the lowest temperature in the pumping line. Additional pollution can come onto the back of the window from the outgassing of inappropriate sealants inside the spectrometer, and in vacuum spectrometers, from back streaming oil from vacuum pumps.

A common question is: how often to clean the window? As suggested above, there is no general answer, because of variations in source designs and varying workloads on instruments. But the best approach is to monitor changes in intensities at various wavelengths over time, e.g. in run charts. Always use the same experimental conditions (method) and the same samples. If intensities are dropping, it is probably due to a dirty window. Cleaning the window should restore intensities to their earlier values. After a while, it will become clear how often cleaning is necessary.

Sometimes operators have noticed intensities drop quickly soon after cleaning the window and then more slowly. Under these circumstances, they prefer to clean less often, i.e. to accept lower intensities in exchange for long- term stability. Clearly, in these cases there is a source of pollution that only slightly covers the window. In an ideal world, it would be better to fix the source of pollution than accept lower intensities.

7 Designing a Standard Test

After these general considerations on checking instrument performance, many readers might now expect us to provide them with a plan for their routine checks, defining which parameters must be checked and how often. Considering, however, that there is really no such thing as a ‘good’ or ‘bad’ instrument, but just instruments that either meet specifications or do not, it is rather difficult to write such a general document.

International Standards Organisation (ISO) standard 10012 requires that all measurement tools, i.e. those used for serious measurement, must be checked to see whether they meet the requirements for the task or not. These checks must be performed at regular intervals. The nature of the checks and their check interval must allow the user to assure that the measurement tool is adequate for use.

For a GDOES instrument, this means that all physical properties that may influence the analytical results, and we have identified many of them in this chapter, must be checked on a regular basis. To avoid spending more time checking the instrument than doing analysis, it is sensible to choose the intervals to be as long as possible. It is therefore suggested to monitor key parameters on a daily basis when the instrument is new. As the amount of data increases, you can derive new, hopefully longer, intervals based on the variations in parameters, their influence on the final analytical result and your analytical requirements (precision and accuracy). This ensures that you meet ISO standards, and that your analytical results are as good as you need them to be.

8 Shutdown

There are two approaches for shutting down an instrument for the night:

• Leave everything on, on the basis that being on promotes thermal stability and minimises interruptions and possible power spikes.

• Turn off as much as possible, on the basis of saving energy and prolonging life by minimising use.

Each has its advantages and disadvantages. Leaving everything on will mean:

• fast start up in the morning

• possibly a more stable instrument, but

• more prone to power outages overnight

• more pollution from the oil pump(s)

The disadvantages can be minimised by ensuring the instrument will restart correctly after a power failure, and by having a small argon leak into the pumps to reduce the back diffusion of oil. Note that not all instruments use oil pumps. Turning most things off will mean:

• saving energy

• possibly extending the life of the instrument, but

• possible damage from surges during start up

• slower start up in the morning, especially waiting for the oil pump(s) to reach equilibrium temperature (typically 1 hour)

The disadvantages can be minimised by always starting in the same sequence and by having oil pumps turn on automatically with a timer about 1 hour before starting work.

Whichever approach is adopted, it is advisable to keep the source closed overnight, to reduce contamination of the source by air and moisture, which could then affect early analyses the next day. This can be done by placing a flat sample (e.g. a glass slide, a small metal sheet or the cooling block, if appropriate) on the source and then closing the valves to the pump(s) so that the source is left under vacuum but without argon and without being pumped. The pump(s) may then be turned off if you wish. This exact procedure may not be possible on all instruments but it should be possible to place some form of temporary cover on the source overnight. Check that the procedure used does not mean that a large quantity of argon is being consumed all night.

Nitrogen-purged spectrometers should be kept purged overnight; large vacuum spectrometers should be kept evacuated overnight. Should it be necessary to stop the nitrogen or vacuum pumps, perhaps for other maintenance in the laboratory, care should be taken when switching off the instrument to ensure the spectrometer is left in a suitable state. Refer to your user’s manual. Later, when restoring the instrument, purging or evacuating the spectrometer to a level where intensities in the far UV are stable may take several hours. It may also take some hours for the spectrometer to reach a constant temperature, in particular when the operating temperature of the spectrometer is above the temperature of the laboratory environment.

For vacuum spectrometers, intermediate pressures, i.e. pressures between about 10 and 10 000 Pa (0.1 and 100 mbar), are dangerous for photomultipliers, because a glow discharge can be ignited around the tubes at the high-voltage supply connection. Normally, the electronics does not allow the high voltage to be switched on at these pressures. During pump-down, therefore, high voltages to the spectrometer should be switched off.
